The main material used for making this milling tool is solid carbide.
Solid carbide material provides unmatched cutting performance, longer tool life and high process security.
It also guarantees exceptional quality, wear-resistance, hardness and rigidity, which are all vital for making milling tools.
Another material used for making this End mill is known as tungsten carbide.
Ordinarily, this material consists of equal parts of tungsten and carbon atoms, making it one of the ideal options for carbide end mill.
It makes end mills, which are tough, wear-resistant and enables high-efficiency machining and chipping properties.
Furthermore, end mills made from this material deliver stable performance in heavy cutting, thus suitable for pre-finish grooving and side-milling operations.
| Grade | ISO Application Area | Grain Size (μ m) | Cobalt Content (%) | Hardness (HRA) | Density (g/cm³) | T.R.S (N/mm³) | Grades Applications recommmended |
|---|---|---|---|---|---|---|---|
| HY06A | K05-K10 | 0.4 | 6.0 | 94.0 | 14.80 | 3800 | Ultrafine grain size,with amazing wear resistance.High wearresistance endmill and engraving tools are recommended.Suitable for cutting PCB and composite material. |
| HY08A | K10-K20 | 0.4 | 8.5 | 93.5 | 14.52 | 3800 | Ultrafine grain size,with good wear resistance.High wearresistance endmill and engraving tools are recommended.Suitable for cutting PCB and plastic. |
| HY12A | K20-K40 | 0.4 | 12.0 | 92.5 | 14.10 | 4200 | Ultrafine grain size,higher Co content;with excellent hardnessand toughness.Endmill and reamer are recommended.Excellent performance for finishing.Especially suitable forcutting steel(HRC:45-55),Al alloy and Ti alloy. |
| HY10 | K20-K40 | 0.6 | 10.0 | 91.7 | 14.40 | 4000 | Drill and endmill are recommended.Suitable for cutting generalsteel (HRC<48)、grey cast iron、stainless steel and heatresistant alloy. |
| HY10A | K20-K40 | 0.5 | 10.3 | 92.3 | 14.30 | 4200 | Drill and endmill are recommended.Especially suitable forcutting stainless steel,heat resistant alloy,cast iron. |
| HY12 | K20-K40 | 0.5 | 12.0 | 92.0 | 14.10 | 4200 | Endmill and reaming for high hardness material are recommended.Sutable for cast iron、stainless steel |
| HY06 | K10 | 0.6 | 6.0 | 93.3 | 14.90 | 3800 | Endmill and reaming for high hardness material are recommended.Sutable for cast iron、stainless steel |
| HY15 | K30-K40 | 1.5 | 15.0 | 87.6 | 14.0 | 4000 | Suitable for making punching of moulds、tools and anti-vibration boring bar etc. |
